Tray Lift Motor (Lower)

SM 3 D693

PAPER FEED

UNIT PB3160

(D693)

1.3 TRAY LIFT MOTOR (LOWER)

1. Rear cover ( page 1)

2. Tray lift motor (lower) [A] (

×2, ×1)
