Ricoh D148 - Original Width Sensor; Interval Sensor

Original Width Sensor / Interval Sensor
D683 20 SM
1.14 ORIGINAL WIDTH SENSOR / INTERVAL SENSOR
1. Feed cover (page 9 "Feed Cover")
2. Guide plate [A] (
×3)
3. Interval sensor [A] ( ×1, ×1)
4. Remove the original width sensor guide plate [A] (
×2), then remove the original width
sensors (
×5) [B] (hook×1 each)
