Ricoh D148 - Control Board

Control Board
SM 7 D690
INTERNAL
FINISHER
SR3130
(D690)
1.6 CONTROL BOARD
 When a control board is replaced, use the same DIP switch settings as those of the
control board before replacement.
1. Finisher front cover (
page 3 )
2. Control board [A] (
×3, ×17)
