Paper Feed
SM 4-117 D146/D147/D148/D149/D150
and Adjustment
4.14 PAPER FEED
§ The 1st paper feed unit can be removed without removing the duplex unit (just open the
right cover), and you can remove the paper feed unit after pulling out the paper tray.
§ Note that the 1st paper feed unit and 2nd paper feed unit are not interchangeable.
§ Note that the 1st paper feed unit for the D150 is not interchangeable with the 1st paper
feed unit for other models.
4.14.1 PAPER FEED UNIT
1st Paper Feed Unit
1. Open the right cover [A] wide ( ×2).
2. Pull out the 1st paper tray [A].
3. Paper feed guide plate [A]
To Next Page
