Transfer Home Position Sensor

D695 4 SM

1.4 TRANSFER HOME POSITION SENSOR

1. Pull out the paper tray.

2. Left cover [A] (

×1)

3. Transfer home position sensor unit [A] (

×1, ×1, ×2)
