Ricoh D148 - Left Lower Cover

To Next Page

To Previous Page

Exterior part

D686/D687 10 SM

1.1.13 LEFT LOWER COVER

1. Front cover ( page 1)

2. Rear cover (

page 3)

3. Booklet tray (

page 8)

4. Left lower cover [A] (

×2)
