Lower Limit Sensor

SM 9 D695

LCIT PB3170

(D695)

1.7 LOWER LIMIT SENSOR

1. Right tray (( page 2)

2. Rear cover (

page 1)

3. Tray lift-transport unit (

page 12)

4. Lower limit sensor [A] (

×1)
