Front Corner Cover
1. Left top cover (page 9 "Left Top Cover")
2. Center top cover (page 10 "Center Top Cover")
3. Right top cover (page 10 "Right Top Cover")
4. Remove the screws at the top of the front corner ( x3).
5. Remove the screws at the bottom of the front corner [A] ( x2).
Exterior Covers
11
