Ricoh LCIT RT5100 - Tray 1 Transport Sensor

3. Tray 1 vertical transport motor 2 [A] ( x2)
• When installing the motor, refer to re-installation for the bypass transport motor 2 (page 55
"Bypass Transport Motor 2").
Tray 1 Transport Sensor
1. Vertical feed unit (page 59 "Vertical Feed Unit")
2. Shoulder screw [A]
1. Replacement and Adjustment
64
