Ricoh LCIT RT5100 - LCIT Paper Length Sensor 1 and 2

3. Paper lower limit sensor [A] ( x1, x1)
LCIT Paper Length Sensor 1 and 2
1. Open the paper tray.
2. Hold the side fence lock to open the side fence [A].
3. Sensor cover [A] ( x2)
1. Replacement and Adjustment
32
