Ricoh LCIT RT5100 - Rear Side; Main Board; Tray 1 Pickup Belt Motor

3. Hold down the lock lever [A] and lower the plate [B] in the direction of the arrow.
4. Side fan [A] ( x2, x1)
1. Replacement and Adjustment
46
