4. Adjustments RICOH Ri 2000 User Manual
176
Press [PRINT].
The adjusting head pattern of the selected printer head is printed.
After finding an appropriate adjustment value, form the print result of the
adjustment pattern.
1. Find a pattern with a square in the lightest color and vertical lines on both sides
that are the straightest (or closest to this condition) aligned in row A.
Note that the value indicated over the pattern indicates an appropriate adjustment value.
An appropriate adjustment value is “+2” in this example.
2. Enter this value in the box for ROW A (the up arrows make the value go up and
down arrows make the value go down).
3. Repeat this for the other rows in the test pattern (B, C, etc.).
To Next Page
