Ricoh Ri 2000 - Unpacking

1. Before You Begin RICOH Ri 2000 User Manual
24
Unpacking
• The machine weights around 140 kg (308 lb.).
• Six or more people are required to lift the printer. When moving the printer, lift it slowly so that you
do not strain yourself. Lifting the printer forcibly or handling it roughly to drop it will risk injury.
Keep the shipping box in the proper orientation. (see arrows on the shipping box).
Remove the poly wrap and strapping.
Remove the top lid, upper foam, and separator sleeve.
Place the printer on your table.
IMPORTANT! Do not lift by the platen or platen base, lift from box with the help of 6 people.
Be sure to hold the parts indicated by the decals on the side of the machine.
The same labels are also attached to the left side.
There is a handle on the bottom of the machine at the label positions.
Have 6 people grab a handle and lift it slowly.
