1. Before You Begin RICOH Ri 2000 User Manual
34
Attaching the Platen
Attach the platen.
The two protrusions on the back of the platen should be set correctly into the holes in the platen
base.
There is a hole on the back side of the platen base that has a guide shape.
When setting the platen, it is easier to insert the pin to the back side when viewed from the front
of the machine.
Network Connection
Insert the ethernet cable into the Ethernet port.
Configure the network settings.
For details about configuring such settings, see page 49, “The setting of IP address for the
machine”.
To Next Page
