9. Troubleshooting Guide RICOH Ri 2000 User Manual
222
Put a tray or paper under the head.
The tray or paper prevents solid ink, lint, and cleaning liquid from entering the machine.
Move the head protection cover under the white carriage.
We recommend that the head protection cover be moved under the carriage by standing on the
right side of the printer, in front of the maintenance unit, and passing it through the guide rods
from above.
To do so, hold the right side of the head protection cover (the side with the two claws at the top)
as shown below to make it easier to attach the cover to the carriage. Note the orientation of the
head protection cover.
To Next Page
