Ricoh SR4110 - Inner Cover; Side Table and Upper Tray

2.Replacement and Adjustment
26
Inner Cover
1. Remove the inner cover [D]/\. ( x 3)
Side Table and Upper Tray
1. Remove the side table [A]. ( x 2). Slide to the right to remove it.
2. Click the release lever [B] and remove the upper tray [C].
