1.Detailed Descriptions
21
No. Description No. Description
1 Feed Out Motor 3 Feed Out Belt
2 Feed Out Belt HP Sensor
No. Description No. Description
1 Exit Open/close Motor 2 Exit Open/close Sensor
Punch (2-hole Punch Unit)
Note: MP1350 cannot punch
The punch unit makes holes in the rear edge of each sheet, one sheet at a time.
3-hole punching can be enabled by a UP mode switch.
