3. Service Tables
Dip Switches
DIP SW100
DIP SW100 settings are for designer and factory use only. Do not change them.
DIP SW 101: 1 to 4
DPS100 Description
1 2 3 4
0 0 0 0
Default
1
0 0 0 Free run: 135 ppm (649 mm/s) A4 LEF, 5 sheets
0
1
0 0 Proof tray free run for durability testing: proof tray + punch + junction gate operation + proof
tray output.:
0 0
1
0 Shift free run: Shift mode simulation 136 ppm (649 mm/s) A4 SEF, 5 sheets, continuous
punching 110 ppm (515mm/s)
0 0 0
1
Sensor check before shipping, lowering the tray before shipping.
DFU. Do not change.
