2.Detailed Descriptions
68
No. Part
4 Booklet Exit Sensor 1
5 Fold Plate Cam HP Sensor
6 Fold Transport Motor
7 Press Fold Motor
Punch Units
No. Part
1 Punch Movement Motor
2 Punch Unit HP Sensor
3 Punch Registration HP Sensor
4 Punch Registration Motor
5 Punch Registration Sensor
6 Punchout Hopper Full Sensor
7 Punch HP Sensor
8 Punch Motor
9 Punch Motor Rotation Sensor
10 Punch Unit Control Board
