PERFORMER Digital Partyline, User Manual, Version 2.30
Function TALK Key
TALK ON Red 100%
TALK OFF (default mode) Red 10%
TALK ON but MUTED Red 100% slow flashing
TALK OFF and MUTED Red 10%
DPL Power Failure (TALK A) Blue 100%, Red 0%
3.2.8 CALL (2 Functions)
Light Call (Momentary)
A flashing CALL key (channel key block) indicates an incoming call on the related digital
partyline channel. Activate the LISTEN key and turn on the volume to listen to the channel.
To send a light call, press the CALL key of the DPL channel you wish to call.
Signalization CALL Key
Incoming CALL Yellow 100% flashing
Outgoing CALL Yellow 100%
Inactive CALL (default mode) Yellow 10%
Light Call (Momentary) with GPI Out Relay
A flashing CALL key (channel key block) indicates an incoming call on the related digital
partyline channel and automatically closes the corresponding GPI Out relay of the unit (Æ
prerequisite).
Pressing the CALL key sends an outgoing call and closes the GPI Out relay contacts of the
corresponding partyline channels (e.g. for an external call light indication).
Note: The GPI Out relay contact of a unit closes only if the corresponding DIP switches of the
unit are set (
Æ
prerequisite).
Signalization CALL Key
Incoming CALL Yellow 100% flashing
Outgoing CALL + GPI Out Yellow 100%
Inactive CALL (default mode) Yellow 10%
Page 12
