PERFORMER Digital Partyline, User Manual, Version 2.30
6.3.3 Downstream Analogue Input
The downstream connector on the CW-2 can also be used as a local analogue input
Æ DIP switch 6, 7
Connector Pin Values Connect to
J100 4 GND Cable shield
J100 5 Audio In + Cable wire
J100 6 Audio IN - Cable wire
6.4 Specifications
Electrical Properties Values
Audio bandwidth: 50 Hz – 20 kHz
Audio bandwidth (DPL): 50 Hz – 10 kHz
Resolution: 16 bit
Microphone Preamp:
Mic input impedance 1 kOhm
Dynamic mic input level -52 dBu
Electret mic input level -38 dBu
Frequency response 80 Hz to 12 kHz, ± 3 dB
Headphone Amplifier:
Load impedance 32 to 600 Ohms
Max. output level 24 Volts peak-to-peak
Max. output power 290 mW @ 250 Ohms
Frequency response 20 Hz to 12 kHz, ± 3 dB
Signal-to-noise-ratio > 80 dB (A)
Page 45
