PERFORMER Digital Partyline, User Manual, Version 2.30
8.5 Specifications
Electrical Properties Values
Audio bandwidth: 50 Hz – 20 kHz
Audio bandwidth (DPL): 50 Hz – 10 kHz
Resolution: 16 bit
Input voltage 100V-240V AC
Power Supply
Power consumption 250VA max.
Input frequency 50-60 Hz
Output voltage 48V DC
Max. load current (all outputs) 3A
Mechanical Properties
Height 44mm (1RU)
Width 485mm (19“)
Depth 250mm (9.8”)
Weight 3.5 kg (7.7 lbs)
General
Temperature range -10 to +50 C (14 to 122 F)
Page 65
