PERFORMER Digital Partyline, User Manual, Version 2.30
5.4 Specifications
Electrical Properties Values
Audio bandwidth: 50 Hz – 20 kHz
Audio bandwidth (DPL): 50 Hz – 10 kHz
Resolution: 16 bit
Microphone Preamp:
Mic input impedance 1 kOhm
Dynamic mic input level -52 dBu
Electret mic input level -38 dBu
Frequency response 80 Hz to 12 kHz, ± 3 dB
Headphone Amplifier:
Load impedance 32 to 600 Ohms
Max. output level 24 Volts peak-to-peak
Max. output power 290 mW @ 250 Ohms
Frequency response 20 Hz to 12 kHz, ± 3 dB
Signal-to-noise-ratio > 80 dB (A)
Power Supply:
Power requirements 36-48 V DC
Power consumption 22 mA / 50 mA @ 48 V
Dimensions:
H x W x D 140 (6) x 120 (4,7) x 39 mm (1,5 inch)
Mass 450 g (0.99 lb)
