PERFORMER Digital Partyline, User Manual, Version 2.30
Upstream
The upstream connector is for connecting the CW-2 to the preceding piece of equipment on
the partyline (ÆJ100 pin out for details).
Downstream
The downstream connector is for connecting the CW-2 to the next piece of equipment on the
partyline (ÆJ100 pin out for details).
Audio Line Connector
The headset / speaker audio signal is also fed to a line out interface. The level of this
symmetrical output depends on the volume of channel A / B.
Connect the external analogue audio device as shown in the J101 pin out.
48V Supply Input
The CW-2 provides a 48V DC input to power the digital partyline. The CW-2 can be powered
from this input or with the 48V phantom power that is provided by the partyline.
The 48V DC supply must not exceed this voltage! The DC source must be limited to 1.8 amps.
Connect the external DC supply as shown in the J101 pin out.
6.3.2 Connection to 3-pole XLR cable
Connector Pin Values 3-pole XLR cable
J100 1 GND Pin 1 (XLR connector male)
J100 2 Partyline Upstream + Pin 2 (XLR connector male)
J100 3 Partyline Upstream - Pin 3 (XLR connector male)
J100 4 GND Pin 1 (XLR connector female)
J100 5 Partyline Downstream + Pin 2 (XLR connector female)
J100 6 Partyline Downstream - Pin 3 (XLR connector female)
Page 44
