Riedel Performer C44plus - The Multi-Pin Connector

PERFORMER Digital Partyline, User Manual, Version 2.30
Page 43
6.3 The Multi-Pin Connector
6.3.1 J100 / J101 Connector Pin Out
Connector Pin Values Connect to
J100 1 GND Cable shield
J100 2 Partyline Upstream + Cable wire
J100 3 Partyline Upstream - Cable wire
J100 4 GND Cable shield
J100 5 Partyline Downstream + Cable wire
J100 6 Partyline Downstream - Cable wire
J101 1 GND Optional
J101 2 +48V extern Optional
J101 3 GND Optional
J101 4 Line Out + Optional
J101 5 Line Out - Optional
J101 6 GND Optional
Nominal Cross-section 1.5mm² (single wire)
1.0mm² (finely stranded)
AWG 16
Thread Diameter single wire – 0.3mm – 1.4mm
AWG 22 – 16
Wire Stripping Length 5mm
1 3 5 1 3 5
2 4 6 2 4 6
J100 J101
