PERFORMER Digital Partyline, User Manual, Version 2.30
5.3.2 DIP Switch Functions
SW OFF ON
1 Latched/Auto Momentary Switches between momentary and latched for
TALK A.
In OFF position a short press on the TALK A knob
routes the microphone signal to Channel A.
Another short press turns it off (Latched).
If the knob is pressed and held for longer than 3
seconds it functions as momentary and the
channel is closed as soon and the knob is
released (Auto).
When the DIP switch is in the ON position the
channel is only open as long as the knob remains
pressed (Momentary).
2 Latched/Auto Momentary Switches between momentary and latched/auto
for TALK B.
3 Talk & listen Listen only Talking on channel A is blocked on this station
4 Talk & listen Listen only Talking on channel B is blocked on this station
5 Dynamic
microphone
Electret
microphone
(Phantom
power)
Headset microphone setting
Changing the DIP switch to ON lowers the audio
amplification by -20dB
6 Daisy Chain Local Input
mixed to CH B
When Local Input is active, the downstream
connector (3-pole male XLR connector) becomes
an analog input. The analog audio signal will be
locally mixed onto Channel B. The analog audio
input level can be adjusted using the CALL and
SCALL keys when TALK is not active.
CALL: Level ++ / SCALL: Level --
7 Daisy Chain Local Input
mixed to CH A
Downstream becomes analog input (see above)
8 OFF Side Tone
Adjustment
In ON position the side tone can be adjusted up
or down using the Channel A knob. The CALL LED
will blink to indicate that the DIP switch is ON.
After the side tone has been adjusted SW-8 must
be returned to the OFF position!
5.3.3 Upstream
3-pole female XLR connector - Digital data stream FROM the party line (female), not powered
by unit. Use this connector to connect upstream devices such as master stations.
5.3.4 Downstream
3-pole male XLR connector - Digital data stream TO the party line (male), not powered by the
unit. Use this connector to daisy chain other digital partyline devices to the C3.
Pay attention if this connector is configured as analog input. Always use a balanced
transformer output to isolate the attached equipment against the DC-Voltage of the Beltpack.
