PERFORMER Digital Partyline, User Manual, Version 2.30
6.2.5 HS Key (momentary)
Pressing the HS (headset) key selects between the headset mode and the speaker mode.
The two LEDs indicate which mode is currently active.
It is recommended not to change the mode while a TALK A or TALK B is active (indicated by
the green talk LEDs).
Status LED
Headset ON, Speaker OFF Green 100%
Speaker ON, Headset OFF Red 1000%
6.2.6 Microphone Connector
The microphone connector is Riedel’s standard 6.3mm microphone connector for electret
microphones, such as MIC 30 / MIC 3 (optional). Turn the microphone connector clockwise to
attach the microphone to the unit.
6.2.7 Headset Connector
The headset connector is 4-pole male XLR connector and supports headsets with electret
(~4.5V) or dynamic microphones, depending on the DIP switch setting.
Setting
DIP SW 5 ON Electret
DIP SW 5 OFF Dynamic
6.2.8 Error LED (red)
The error LED indicates that the bit error rate has exceeded the range tolerated. This is
usually caused by a defective cable or a cable run that is too long. The partyline cannot be
used in this case.
Status Error LED
Partyline error occurred Red 100%
Partyline works fine Red 0%
Page 39
