PERFORMER Digital Partyline, User Manual, Version 2.30
PIN PIN
1 AUX In +
2 GND 9 AUX In –
3 Aux Out + 10 AUX Out –
4 GPI Out 1 (Line 2 CH A) 11 GPI Out 1 (Line 2 CH A)
5 GPI Out 2 (Line 2 CH B) 12 GPI Out 2 (Line 2 CH B)
6 Empty 13 Empty
7 Empty 14 Empty
8 GPI Out SA 15 GPI Out SA
AUXILIARY IN / OUT
If DIP switch 6 (for CH A) and / or DIP switch 7 (for CH B) is in the ON position, the auxiliary
audio (system 4-wire) is permanently routed to the related digital partyline channel.
SA GPI out Relay
The stage announcement SA GPI out closes when the SA key is pressed.
GPI out Relay
The channel auxiliary GPI of the corresponding partyline closes when the GPI key is pressed
AND the DIP switch 6 / 7 is in position ON.
Note: An adapter snake cable to 3 pole XLR 3 is optional available (Adapter Cable CR-2)
4.3.3 PGM IN Connector
3-pole female XLR connector - Symmetric analog audio input (local 4-wire) for e.g. local
program input (PGM).
Level adjustment with screw trim right next to it. Turn the screw clockwise to increase the
level and counterclockwise to decrease it.
4.3.4 SA OUT Connector
3-pole male XLR connector - Symmetric analog audio output (local 4-wire) for e.g. stage
announcement (SA)
4.3.5 Upstream Connector
3-pole female XLR connector - Digital data stream FROM the party line (female), not powered
by unit. Use this connector to connect upstream devices when the CD-2 is used within a
system.
