PERFORMER Digital Partyline, User Manual, Version 2.30
5.2.2 CALL LED (orange)
The CALL LED lights orange when the CALL key is pressed and TALK is active. If an incoming
call is received the CALL LED blinks bright orange alternating with the green LED of the
channel being called.
Note: When the C3 beltpack is in side tone mode, this combination blinks dimmer than it
does when the beltpack is being called (DIP SW8 ON).
Status CALL LED
Outgoing CALL Orange 100%
Incoming CALL Orange 100%, flashing
Side tone adjustment Orange 50%,
flashing fast
5.2.3 Channel A/B LED (green)
This LED blinks green when an incoming call signal is received, as well as when a channel
being called is not active. The LED lights sold green when the channel is turned on.
Status Channel LED
TALK active Green 100%
Incoming CALL to Channel Green 100%, flashing
5.2.4 Power LED
The Power LED lights red when the beltpack is correctly powered (36V - 50V).
Status Power LED
Powered, ON Red 100%
Insufficient powered, OFF Red 0%
5.2.5 Channel Knob (2 Functions)
Volume Channel A/B
The channel volume knob levels the channel volume of the C3 (0-100%). Turn the knob
clockwise to increase and counterclockwise to decrease the volume of the channel. The
channel is MUTED when the encoder is turned counterclockwise as far as it will go.
TALK Channel A/B (Auto / Momentary)
Pressing the left knob activates the TALK for channel A. This is indicated by the green LED.
Pressing the right knob activates the TALK for channel B. An active TALK key enables talking
to the corresponding digital partyline channel. The TALK key can be set to auto or momentary
mode by the DIP switch 1 for channel A and 2 for channel B at the bottom side of the C3.
Page 33
