PERFORMER Digital Partyline, User Manual, Version 2.30
4.2.1 Microphone Connector
The microphone connector is Riedel’s standard 6.3mm microphone connector for electret
microphones, such as MIC 30 / MIC 3. Turn the microphone clockwise to attach the
microphone to the unit.
4.2.2 Headset Connector
The headset connector is 4-pole male XLR and supports headsets with electret (~ 4.5V) or
dynamic microphones, depending on the DIP switch setting.
Setting
DIP SW 5 ON Electret
DIP SW 5 OFF Dynamic
4.2.3 Headset Knob (2 Functions)
Volume Control
The headset rotary encoder adjusts the volume (0-100%) of the headset speaker. Turn the
encoder clockwise to increase and counterclockwise to decrease the volume. The volume is
MUTED when the encoder is turned counterclockwise as far as it will go.
Headset Microphone ON / OFF
Pushing the rotary encoder switches between gooseneck and headset microphone.
Note: Selecting the headset microphone does not automatically mute the panel speaker!
Selection LED
Headset Microphone Green 100%, ON
Gooseneck (default mode) 0%, OFF
4.2.4 SIDE TONE Adjustment Headsets
The side tone of the headset can be adjusted by the screw trim. Turn the screw clockwise to
increase the side tone and counterclockwise to decrease it. The side tone is OFF when the
screw is turned counterclockwise as far as it will go.
Note: The side tone is only active when either the TALK or the SA (stage announcement key
(function key block) is active. The side tone is never routed to the loudspeaker.
Page 21
