Chapter 1 Quick Start RIGOL
User’s Guide for DP1116A
1-5
② ④
Sense terminal
Compensate the voltage drop.
③
Power output
terminals
Output the power supply.
④
Earth terminal
This terminal is connected with the chassis and ground
wire (grounded through the power cord) and can be
used as an additional ground terminal for other devices
when the instrument is power on.
