Figure 2-2 Pop-up box input
(2) O.V.P and O.C.P setting
Press O.V.P or O.C.P and enter a desired parameter, for the detailed entry
method, please refer to “Voltage and Current setting”.
(3) Calibration and Timer setting
Press Calibrate or TimerSet and enter the desired values. Note that the unit
you specify should match with the current parameter, for example, only “mV” or
“V” can be used for the voltage you are setting.
2. Direct parameter input (modify): this method applies to the following
settings.
(1) Voltage and Current setting
Switch to the General display mode or Waveform display mode.
Press the Volt or Curr panel key at the front panel and the cursor is then
moved into the corresponding parameter input box.
Increase or decrease the voltage or current value displayed at which the
cursor is located by pressing the up (V) or down (mV) direction key. To
move the cursor, pressing the left (mA) or right (A) direction key.
