Rigol DP1116A - Page 52

RIGOL Chapter 2 Front Panel Reference
User’s Guide for DP1116A
2-26
Figure 2-20 USB ID information
3. GPIB
Press I/O→GPIB and enter the interface shown below. The GPIB address
ranges from 1 to 30. You can enter a desired value using the numeric keys and
press OK to save. To delete the entered digits, press “←”.
Figure 2-21 GPIB address setting
