1. By USB
Please follow the steps below:
(1) Connect the instruments
Use a USB data cable to connect the USB Device port of your DP1116A to the
USB Host of a PC.
(2) Install the USB driver
DP1116A is a USBTMC unit. After you connect it with the PC correctly, turn on
the instrument (the instrument will automatically use the USB interface), a
dialog appears on the PC screen and guide you to install the “USB Test and
Measurement Device” driver.
(3) Search the available device
Open the Ultra Sigma, the software will automatically search the instruments
that connected to the PC through the USB port. You can also search the device
through clicking . The status bar of the software during the
search is:
Figure 3-7 Status bar of USB seraching
(4) View the available devices
Devices that have been detected will be listed under the “RIGOL Online
Resource” in connection with their own model, USB information. See figure
below:
