RIGOL Chapter 6 Operations and Measurements
6-12 MSO4000/DS4000 User’s Guide
You can perform the logic operations following the steps below.
1. Select the logic operation
Press MATH Operate, turn the multi-function knob to select “Logic” and
press the knob. You can also press Operate continuously to switch to the
“Logic” operation.
2. Specify the logic operation formula
Press Formula, turn the multi-function knob to select the desired logic
operation expression and press the knob. You can also press Formula
continuously to switch the logic operation formula currently selected. The
formulas available include AND, OR, NOT and XOR. The default is AND.
For the detailed introduction of each logic operation formula, refer to Table 6-2.
3. Specify source A and source B
1) Press Source A, turn the multi-function knob to select the desired
channel and press the knob. You can also press Source A continuously to
switch the channel currently selected. The channels available are CH1 to
CH4 and D0 to D15.
2) Press Source B and use the same method to select the signal source of
source B.
4. Adjust the vertical scale and vertical position
Press
and respectively; turn the multi-function knob to adjust the
vertical scale and vertical position of the math operation waveform. Please refer
to “MATH Waveform Vertical Control”.
5. Adjust the horizontal time base and horizontal position
Use HORIZONTAL
SCALE and HORIZONTAL POSITION to adjust
the horizontal time base and horizontal position of the math operation waveform
respectively. For the adjustment methods, please refer to “
To Adjust the
Horizontal Time Base” and “To Adjust the Horizontal Position”.
Note: Turning HORIZONTAL
SCALE and HORIZONTAL POSITION
will adjust the horizontal scales and horizontal positions of the channel
waveforms and math operation waveform at the same time.
