RIGOL Chapter 7 Logic Analyzer
7-10 MSO4000/DS4000 User’s Guide
To Set the Digital Channel Label
By default, the instrument uses D0 to D15 as the channel labels of the 16 digital
channels. To identify different channels conveniently, you can define a label for each
digital channel. You can use the preset label or input the label manually.
Press LA Label to enter the label setting submenu.
1. Select the specified digital channel
Press Sel CH and turn the multi-function knob to select the desired digital
channel. You can also press Sel CH continuously to switch the current digital
channel. You can select any channel from D0 to D15.
2. Set the user-defined label
Use the preset label
Press Preset; turn the multi-function knob to select the desired label
and press the knob. You can also press Preset continuously to switch the
current preset label. The preset labels available include ACK, AD0, ADDR,
BIT, CAS, CLK, DATA, HALT, INT, UB, LOAD, NMI, OUT, PIN, RAS, RDY, RST,
RX, TX and WR.
Input a label manually
Press Input to open the label submenu and the label modification interface.
Please set the digital channel label by referring to the instruction in “
To Set
the Channel Label”.
Note: The user-defined label can include uppercase English letters (from A
to Z), lowercase English letters (from a to z), numbers (from 0 to 9),
underline (_) and space; the length of the label cannot exceed 4 characters.
