Chapter 10 Pass/Fail Test RIGOL
MSO4000/DS4000 User’s Guide 10-9
To Save the Test Mask Range
When the pass/fail test function is enabled, you can save the current test mask range
to the internal memory or external USB storage device (only when a USB storage
device is detected) in “*.pf” format. The internal memory can store at most 10 test
mask files (LocalPF0.pf to LocalPF9.pf).
Note: For the test mask range, please refer to “To Set the Test Mask”.
1. Press Utility  Pass/Fail  Enable and select “ON” to enable the pass/fail
test function.
2. Press Save to enter the file store interface. Please refer to the relative
descriptions in “
Store and Recall” to save the test mask file to the internal or
external memory.
To Load the Test Mask Range
When the pass/fail test function is enabled, you can load the test mask file stored in
the internal memory or external USB storage device (only when a USB storage device
is detected) and apply it to the current pass/fail test function.
1. Press Utility  Pass/Fail  Enable and select “ON” to enable the pass/fail
test function.
2. Press Load to enter the file recall interface. Please refer to the relative
descriptions in “
Store and Recall” to load the specified test mask file (*.pf)
and apply it to the current pass/fail test function.
