RIGOL Chapter 3 Horizontal System Setting
3-10 MSO4000/DS4000 User’s Guide
To Turn Delayed Sweep On/Off
Delayed sweep can be used to enlarge a length of waveform horizontally to view the
waveform details.
Note: Delayed sweep can only be turned on when the current time base mode is
“Y-T” and the “Pass/Fail” test is off.
Press MENU in the horizontal control area (HORIZONTAL) and press Delayed to
turn delayed sweep (the default is off) on or off. You can also press HORIZONTAL
SCALE to quickly switch the on/off status of the delayed sweep.
When delayed sweep is turned on, the screen is divided into two display areas as
shown in the figure below. The waveform of normal sweep is displayed in the upper
part of the screen and its horizontal time base (called main time base) is displayed at
the upper-left side of the screen. The delayed sweep waveform (the horizontally
expanded waveform) is displayed in the lower part of the screen, its horizontal time
base (called delayed sweep time base) is displayed at the middle of the screen and
its horizontal position (called delayed sweep horizontal position) is displayed at the
upper-right side of the screen. At this point, HORIZONTAL
SCALE is used to
adjust the delayed sweep time base; HORIZONTAL
POSITION is used to
adjust the delayed sweep horizontal position.
