RIGOL Chapter 13 Store and Recall
13-12 MSO4000/DS4000 User’s Guide
To Create a New File or Folder
This operation is only valid in external storage. Before performing the operation,
make sure that a USB storage device is connected correctly.
1. Press Storage Disk.Manage; turn the multi-function knob to select the
external disk (“Disk D” or “Disk E”) and press the knob to open the disk.
2. Turn the multi-function knob to select the desired directory under which to
create a new file or folder. The default is the root directory of the USB storage
device (D:\). The current directory is displayed at the upper-left corner of the
disk management interface.
3. Press File Type to select the desired file type and press New File or directly
press New Folder to open the filename input interface as shown in the figure
below.
This oscilloscope supports Chinese/English input method. The filename or folder
name can contain letters, numbers, underscores, spaces and Chinese characters and
the length of the characters is limited to 31 bytes (one Chinese character occupies
two bytes). Please input the desired name to create a new file or folder by referring
to “English Input Method” and “Chinese Input Method”
Tip
During t
he name input, use the menu softkeys to select different operation areas,
then turn the multi-function knob to select the desired content and press
down the knob to input the content selected.
