Chapter 13 Store and Recall RIGOL
MSO4000/DS4000 User’s Guide 13-13
English Input Method
The English input method interface is as shown in the figure below.
Figure 13-3 English Input Method Interface
Name Input Area: display the characters currently input.
Keyboard: used to input the specified character.
Upper-lower Case Switch: used to switch between English uppercase and
lowercase inputs.
A
a”denotes lowercase and “
a
A” denotes uppercase.
Input Method Switch: used to switch between English and Chinese input
methods.
Example: create a file or folder with the name “Filename”
In the filename input interface,
1. Select English input method
If the current input method is “En”, please move to step 2. If the current input
method is “”, turn the multi-function knob
to select “” and press the
knob to switch to “En”.
2. Clear the name input area
If there is no character in the “Name Input Area”, please move to step 3. If there
are characters in the “Name Input Area”, press Delete to delete all the
characters in the name input area in order.
3. Input the first character “F”
1) If the current upper-lower case is “
a
A” (uppercase), please move to step 2).
If the current upper-lower case is “
A
a” (lowercase), press Keyboard to
select the “Keyboard” area, turn the multi-function knob
to select “
A
a”
Name Input Area Keyboard Upper-lower Case Switch Input Method Switch
