Rigol DS4024 - Probe Connection and Setup

RIGOL Chapter 1 Quick Start
1-8 MSO4000/DS4000 User’s Guide
To Connect the Probe
RIGOL provides passive and active probes for DS4000 as well as passive, active and
logic probes for MSO4000. For detailed technical information of the probes, please
refer to the corresponding Probe User’s Guide. The probes recommended for this
oscilloscope are as shown in the table below.
Model
Description
RP3500A 500 MHz, passive probe, standard, auto detection
RP7150 1.5 GHz, active probe, optional, auto detection
RPL2316 Logic probe, standard (only for MSO4000 series)
Besides, MSO4000/DS4000 series oscilloscope also supports TekProbe-BNC 2 degree
probes (with RIGOL T2R1000 interface adaptor, option) of Tektronix.
