Chapter 1 Quick Start RIGOL
MSO4000/DS4000 User’s Guide 1-9
To Connect the Passive Probe
1. Connect the BNC terminal of the probe to the analog channel input terminal or
external trigger input connector of the oscilloscope at the front panel (please
refer to “Front Panel Overview”).
Figure 1-6 To Connect the Passive Probe
2. Connect the ground alligator clip or ground spring of the probe to the circuit
ground terminal and connect the probe tip to the circuit point to be tested.
After connecting the passive probe, you need to perform probe function inspection
and probe compensation before making measurements. For the detailed steps, refer
to “Passive Probe Function Inspection&Compensation Adjustment”.
