Chapter 7 Logic Analyzer RIGOL
MSO4000/DS4000 User’s Guide 7-9
the jitter time when no reference clock is set for the digital bus.
Press JitterReject to turn the jitter rejection function on or off.
Press JitterTime and turn the multi-function knob or the inner
knob of the navigation knob to adjust the jitter time at a relatively
smaller step or turn the outer knob of the navigation knob to adjust the
jitter time at a relatively larger step. The adjustable range is from 1 ns
to 1 ms.
Note: The larger the rotation amplitude of the outer knob of the
navigation knob is, the faster the variation of the value will be. When
you need to adjust the jitter time within a relatively larger range, this
function can help you quickly finish the setting.
6. Specify the display type
Press Type to select “Data” or “Graph”.
In the data type, the bus data is displayed directly in the specified format.
Press Format and turn the multi-function knob to select the desired
display format. You can also press Format continuously to switch the
current display format. You can select Hex, Decimal, Binary or ASCII.
In the graph type, you can view the variation trend of the bus.
