(Expression will automatically switch to “OFF”). At this point, the current
expression is displayed at the bottom of the screen. The oscilloscope will
operate according to this expression and display the results.
To Set the Variables
You can specify the variable by setting the “Mantissa” and “Exponent” (use 10 as the
base). For example, when the mantissa is set to 6.1074 and the exponent is set to 8，
the variable is set to 6.1074×10
8
.
Press Variable to open the variable setting menu. You can set the variables
(Variable1 and Variable2) may be included in the operation expression using the
method below.
1. Select the variable to be edited
Press Variable to select “Variable1” and “Variable2”.
Variable1 and Variable2 correspond to Variable1 and Variable2 in the operation
expression respectively.
2. Edit the mantissa
1) Press Step and turn the multi-function knob to select the step used
when modifying the “Mantissa”. You can also press Step continuously to
switch the current step. The steps available are ×1, ×0.1, ×0.01, ×0.001
and ×0.0001.
2) Press Mantissa and turn the multi-function knob to modify the
mantissa at the step specified in Step. The range available is from -9.9999
to 9.9999.
3. Edit the exponent
Press Exponent and turn the multi-function knob to select the desired
exponent. It can be any integer from -9 to 9.
