Chapter 6 Operations and Measurements RIGOL
MSO4000/DS4000 User’s Guide 6-49
You can use cursor to perform track measurement on the waveform of CH1 to CH4 or
MATH channel following the steps below.
1. Turn on the track measurement function
Press Cursor Mode, turn the multi-function knob to select “Track” and
press the knob. You can also press Cursor or Mode continuously to switch to
“Track”. At this point, the oscilloscope measures the specified point of the
specified source channel waveform according to the current setting and displays
the measurement results at the upper-left side of the screen. When the track
measurement parameters are modified, the measurement results will change
accordingly.
2. Specify the track sources
1) Press Cursor A and turn the multi-function knob to select the track
source of cursor A. You can also press Source continuously to switch the
current source. The channels available include CH1 to CH4 and MATH.
When “None” is selected, cursor A and the measurement result will not be
displayed.
Note: Only channels currently turned on can be selected.
2) Use the same method to select the track source of cursor B.
3. Adjust the cursor positions
1) Press CursorA and turn the multi-function knob to adjust the
horizontal position of cursor A (X cursor). The adjustable range is limited
within the screen. The crossing point of the cursors is marked by an orange
rectangle.
2) Press CursorB and turn the multi-function knob to adjust the
horizontal position of cursor B (X cursor). The adjustable range is limited
within the screen. The crossing point of the cursors is marked by an orange
rhombus.
3) Press CursorAB and turn the multi-function knob to adjust the
horizontal positions of cursors A and B (X cursors) at the same time (the
horizontal distance between cursor A and B (X cursors) keeps unchanged).
