RIGOL Chapter 6 Operations and Measurements
6-54 MSO4000/DS4000 User’s Guide
respectively.
 XY2: the X cursors and Y cursors are used to measure the amplitude values
of the specified points (cursor crossing points) of CH3 and CH4 waveforms
respectively.
3. Ajust the X/Y cursor positions
1) Ajust the X cursor positions
 Press Type to select “X”.
 Press CursorA and turn the multi-function knob to adjust the
horizontal position of cursor A (X cursor). The adjustable range is
limited within the screen.
 Press CursorB and turn the multi-function knob to adjust the
horizontal position of cursor B (X cursor). The adjustable range is
limited within the screen.
 Press CursorAB and turn the multi-function knob to adjust the
horizontal positions of cursors A and B (X cursors) at the same time.
The adjustable range is limited within the screen. The horizontal
distance between cursors A and B (X cursors) keeps unchanged.
2) Ajust the Y cursor positions
 Press Type to select “Y”.
 Press CursorA and turn the multi-function knob to adjust the
vertical position of cursor A (Y cursor). The adjustable range is limited
within the screen.
 Press CursorB and turn the multi-function knob to adjust the
vertical position of cursor B (Y cursor). The adjustable range is limited
within the screen.
 Press CursorAB and turn the multi-function knob to adjust the
vertical positions of cursors A and B (Y cursors) at the same time. The
adjustable range is limited within the screen. The vertical distance
between cursors A and B (Y cursors) keeps unchanged.
Note: When any of CursorA, CursorB and CursorAB is currently selected,
you can press the multi-function knob
continuously to quickly switch among
the three items.
