RIGOL Chapter 11 Waveform Recording
11-10 MSO4000/DS4000 User’s Guide
2) Pause the playback operation
During the playback process (the backlight of the playback/pause shortcut
key ( ) is illuminated in yellow and flashes continuously), press Operate
and turn the multi-function knob
to select “ ” and press the knob or
directly press the playback/pause shortcut key (
) at the front panel; the
oscilloscope pauses the playback operation. At this point, the backlight of
the playback/pause shortcut key (
) is illuminated in yellow and is
constant on.
When the playback operation is paused, you can adjust the Current Frame
according to your need (refer to “
Manual Playback”); when the playback
operation is resumed, the oscilloscope will play back from the frame
specified in Current Frame.
When the “Play back” mode is enabled, RUN/STOP can be used to switch
between playback and pause.
3) Stop the playback operation
When the single playback ( ) mode is selected,
Stop manually
During the playback process, press Operate to select “■” or press the
stop shortcut key (
) at the front panel; the oscilloscope stops the
playback.
Stop automatically
The oscilloscope will stop the playback automatically after the specified
number of frames (from Start Frame to End Frame) of waveform are
played back.
When the circular playback ( ) mode is selected,
You can only stop the playback manually.
During the playback process, press Operate and select “■” or press
the stop shortcut key (
) at the front panel; the oscilloscope stops the
playback.
