Rigol DS4024 User Manual

Chapter 13 Store and Recall RIGOL
MSO4000/DS4000 User’s Guide 13-21
Manual
Display Type X-Y
Source Select CH1
Select Cursor X
Time Unit s
Vertical Unit Source Unit
Horizontal Positions of X Cursors
CursorA -4*1 μs
CursorB 4*1 μs
Vertical Positions of Y Cursors
CursorA 2*1 V
CursorB -2*1 V
Track
Cursor A CH1
Cursor B CH1
Horizontal Positions of X Cursors
CursorA -4*1 μs
CursorB 4*1 μs
Storage Setting (Storage)
Storage Type Setups (No USB storage device is connected)
Picture (USB storage device is connected)
Picture Type png
Parameter Save OFF
Invert OFF
Color Setting Color
Header Setting OFF
Footer Setting OFF
CSV
Data Depth Displayed
Parameter Save OFF
Sequence ON
Utility Function Setting (Utility)
I/O Setting
