5.1.5 Editing Option Items
Some settings allow the choice of an option from a predefined list of options. Examples are BUILD:DP or
OPTION:USE. To show/edit:
Press the OK key to show the current setting
Press the up or down keys until the correct setting is shown
Press the OK key to exit the editor
5.1.6 Editing Weight and Number Items
Some settings require the entry of a weight or other number. Examples are BUILD:CAP1 or OPTION:Z.BAND.
The correct decimal point and units (if applicable) are shown while editing. To show/edit:
Press the OK key to show the current setting
Use the left and right keys (change digit) and the up and down keys (increment/decrement digit) to show
the correct value
Press the OK key to exit the editor
– If the setting is not possible (for example if the value is greater than the allowed maximum), ------
is shown and the editor will not exit.
5.1.7 Editing Printable String Items
Some settings require the entry of text. Examples are SERIAL:NET.OPT:ID or ETH.NET:HST.NAM. To show/edit:
Press the OK key to begin editing the string
– A window of the string of up to 6 characters will be displayed
– The currently selected character will flash
Use the left and right keys to move backward and forward through the string
– To extend a string move beyond the rightmost character, and all segments of the digit will flash to
indicate the end of string
Use the up and down keys to modify the currently selected character
– To terminate the string at this point cycle though until all segments are displayed for this character
(indicating the end of string)
Use a long press of the the up key to insert a character before the currently selected character
Use a long press of the the down key to delete the currently selected character
Use a long press of the left key to move to the start of the string
Use a long press of the right key to move to the end of the string
Use the OK key to advance to the next character in the string
Press the cancel key to exit the editor (changes will be saved)
5.1.8 Editing Binary String Items
Some settings require the entry of text or token string containing non-printable characters. Examples are
SERIAL:AUT.OPT:AUT.FMT or SERIAL:PRN.OPT:HEADER. To show/edit:
Press the OK key to show the first character in the string
– The character is shown as xxx.yyy.
– xxx is the character position in the string (e.g: 001, 002, 003, etc).
– yyy is the ASCII code for the character (e.g: 065=’A’, 002=STX). See the ASCII table in Section 9.5.
17 C500-600-2.0.3
