5.9 SET.PTS: Setpoints Menu
This section is used to set all of the operational logic of the setpoint system, as well as provide for the entry
of secure setpoint target and inflight values.
Items Name Description
General GEN General setpoint settings
Jog on time JOG.ON Job on time in milliseconds. Only used for pulse setpoint timing.
Jog off time JOG.OFF Job off time in milliseconds. Only used for pulse setpoint timing.
Jog set JOG.SET Number of jogs in a set. Only used for pulse setpoint timing.
Maximum sets MAX.SET Maximum number of jog sets. Only used for pulse setpoint timing.
Feeder FEEDER Feeder type for weigh in and weigh out setpoints. Options are:
MULT.: Outputs will run in parallel (default)
SINGLE: Outputs will run serially
Delay check DLY.CHK Delay time in milliseconds after weigh in or weigh out setpoint
becomes active before weight is checked again.
Setpoint 1
Setpoint 2
Setpoint 3
Setpoint 4
Setpoint 5
Setpoint 6
Setpoint 7
Setpoint 8
SET.PT.1
SET.PT.2
SET.PT.3
SET.PT.4
SET.PT.5
SET.PT.6
SET.PT.7
SET.PT.8
Setpoint settings
Setpoint type TYPE Set setpoint type. Options are:
OFF: Disabled (default)
ON: Always active
OVER: Weight over setpoint
UNDER: Weight under setpoint
COZ: Centre of zero status
ZERO: Zero band status
NET: Gross/net status
MOTION: Motion status
ERROR: Error status
BUZZER: Buzzer status
W. OUT: Weigh out setpoint
W. IN: Weigh in setpoint
Target TARGET Setpoint target. Only used for weight setpoints.
Hysteresis HYS Setpoint hysteresis. Only used for weight setpoints.
Inflight FLIGHT Setpoint inflight. Only used for weight setpoints.
Lock LOCK Disable operator access (via operator menus). Options are:
OFF(def): menu access available
ON: menu access locked
Source SOURCE Select source for weight setpoints. Options are:
GROSS(def): use gross weight.
NET: use net weight.
Output logic LOGIC Output logic. Options are:
HIGH(def): output is high when setpoint is active.
LOW: output is low when setpoint is active.
31 C500-600-2.0.3
